Описание за RCF P4228
Features
-
Weatherproof cabinet IP 55
-
Aluminium grill and stainless steel bracket
-
Two 8" high-output LF transducer with 2.5" voice coil
-
Once RCF Precision Neodymium 1.4" Compression Driver with 2.5" voice coil
-
110° x 60° constant directivity horn
-
Built in passive crossover
-
2° x 15° enclosure sides for array configurations
-
Active Mosfet Compression Driver Protection
-
LICC (Low Impedance Compensated Crossover) network
Acoustical Specifications
-
Frequency Response -10 dB: 80 Hz ÷ 20 kHz
-
Max SPL @ 1m: 129 dB
-
Horizontal coverage angle: 110°
-
Vertical coverage angle: 60°
-
Directivity index; Q: 9
-
System Sensitivity: 97 dB
-
Nominal Impedance: 8 Ω
-
Power Handling: 400 W
-
Peak Power Handling: 1600 W
-
Recommended Amplifier: 800 W
-
Protections: Dinamyc
-
Crossover frequencies: 1100 Hz
Transducers
-
Compression Driver: 1.4"(35.5mm) throat, 2.5" (63.7 mm) coil diaphragm assembly
-
Nominal Impedance: 8 Ω
-
Input Power Rating: 90 W AES
-
Sensitivity: 110 dB
-
Woofer: 2x8" (200 mm) woofer with 2.5" (64 mm) coil
-
Nominal Impedance: 16 Ω
-
Input Power Rating: 300 W AES
-
Sensitivity: 95 dB
Input Section
-
Input connector: 4 pole Amphenol
Cabinet
-
Cabinet Material: 8 mm Polyethylene rotomoulded
-
Hardware: 4 x M8 + U-bracket and pair of spacers
-
Grille: Custom perforated aluminium grille with open-cell fiber and water repellent woven fabric backing
-
Colour: Gray
Physical Specifications
-
Height: 268 / 10.55 mm/inch
-
Width: 566 / 22.28 mm/inch
-
Depth: 250 / 9.84 mm/inch
-
Net Weight: 13.5 / 29.7 kg/lbs
